EDM Cutting Machine JFC-435( ZNC E.D.M)
- Chief
- Guangdong
- within 30days after payment
- 100sets per month
Chief CNC started from 2001, the technology is from Taiwan. Our EDM machine has the following features:
1. Spindle permanent oil lies design, can ensure spindle continue to operate without for a long time.
2. Z axis used the equipment with industry considered the most precise durable Swiss production linear guide rail, all the assembly holes were using CNC processing center accurate drilling. And experienced technicians assembly, guaranteed to get the smooth sliding. The most perfect the straightness and highest rigidity.
3. X.Y.Z axis all to be the imported ball screw rotation precision, long life, not easy to be damaged.
4. We keep stock for regular models for cnc milling center, can make the shipment within 20days.
EDM cutting machine JFC-435 (ZNC E.D.M)
Features of the machine
Spindle permanent oil lies design, can ensure spindle continue to operate without for a long time.
Z axis used the equipment with industry considered the most precise durable Swiss production linear guide rail, all the assembly holes were using CNC processing center accurate drilling. And experienced technicians assembly, guaranteed to get the smooth sliding. The most perfect the straightness and highest rigidity.
X.Y.Z axis all to be the imported ball screw rotation precision, long life, not easy to be damaged.
Slippery course adopts v-shaped graphic design, and use TURCTE-B wear-resisting piece, Under great pressure, chipped points east lightweight per square inch,20 points above ensure precision decade invariable, and precision in 0.01mm less than.
The integration of casting design, rigid changeless, the accuracy is guaranteed.
Specification of EDM cutting machine JFC-435 (ZNC E.D.M)
| JFZ/ZNC E.D.M | |||||||
| Unit | JFZ-320 | JFZ-430 | JFZ-435 | JFZ-540 | JFZ-650 | JFZ-700 | |
| Work tank | mm | 880x520 x330 | 1130x600 x450 | 1130x710 x450 | 1300X720 X475 | 1650X1100 X630 | 1650X1100 X630 |
| Work table | mm | 600x300 | 650x350 | 700x400 | 800X400 | 1050X600 | 1050X600 |
| Table travel (X) | mm | 300 | 400 | 450 | 500 | 650 | 700 |
| Table travel (Y) | mm | 200 | 300 | 350 | 400 | 550 | 550 |
| Table travel (Z) | mm | 180 | 200 | 200 | 200 | 250 | 250 |
| Workhead travel | mm | 180 | 280 | 280 | 380 | 400 | 400 |
| Table to electrode plate | mm | 420 | 450 | 480 | 580 | 850 | 850 |
| Maxelectrode weight | KG | 100 | 120 | 120 | 150 | 200 | 200 |
| Max workpiece weight | KG | 800 | 1000 | 1200 | 1500 | 2000 | 2000 |
| Machine net weight | KG | 1150 | 1360 | 1460 | 1740 | 2950 | 2950 |
| Packing size | mm | 1300x1250 x1200 | 1430x1180 x1800 | 1470x1150 x1980 | 1640X1460 X2140 | 2000X1710 X2360 | 2000X1710 X2360 |
| Filter box capacity | liter | 250 | 400 | 400 | 460 | 980 | 980 |
| Filtering box net | KG | 150 | 150 | 180 | 300 | 300 | |
Products pictures of EDM cutting machine JFC-435 (ZNC E.D.M)
